STPS200170TV1Y

DIODE MOD SCHOT 170V 100A ISOTOP

Manufacturer: STMicroelectronics

Categories: Diode Arrays

Quality Control: Learn More

STMicroelectronics STPS200170TV1Y is a dual-diode module, featuring two independent Schottky diodes configured for high-power applications. Each diode offers a repetitive peak reverse voltage (Vrrm) of 170V and a continuous average forward current (Io) of 100A. The forward voltage drop (Vf) is rated at a maximum of 850mV at 100A. Reverse leakage current (Ir) is specified at 200 µA at 170V. This component is designed with a Chassis Mount configuration utilizing the ISOTOP® package for efficient thermal management. Operating junction temperatures range from -55°C to 150°C. The STMicroelectronics Q series diode array is qualified to AEC-Q101 standards, making it suitable for automotive applications and other demanding environments requiring robust power rectification.

Additional Information

Series: QRoHS Status: ROHS3 CompliantManufacturer Lead Time: 25 week(s)Product Status: ActivePackaging: TubeDatasheet:
Technical Details:
PackagingTube
Package / CaseISOTOP
Mounting TypeChassis Mount
SpeedFast Recovery =< 500ns, > 200mA (Io)
TechnologySchottky
Diode Configuration2 Independent
Current - Average Rectified (Io) (per Diode)100A
Supplier Device PackageISOTOP®
Operating Temperature - Junction-55°C ~ 150°C
GradeAutomotive
Voltage - DC Reverse (Vr) (Max)170 V
Voltage - Forward (Vf) (Max) @ If850 mV @ 100 A
Current - Reverse Leakage @ Vr200 µA @ 170 V
QualificationAEC-Q101
