L6910GTR
IC REG CTRLR BUCK 16SOICManufacturer: STMicroelectronics
Categories: DC DC Switching Controllers
Quality Control: Learn More
STMicroelectronics L6910GTR is a high-performance, 200kHz buck (step-down) DC-DC controller IC. This 16-SOIC package device features a positive output configuration and a single output phase, driving a transistor for efficient power conversion. The L6910GTR offers comprehensive control features including current limit, frequency control, phase control, power good indication, and soft-start for robust operation. Its surface mount design is suitable for demanding applications across automotive, industrial, and consumer electronics sectors. Operating across a wide temperature range of -40°C to 150°C (TJ), this controller supports a supply voltage range of 5V to 12V, with a maximum duty cycle of 100%. The inclusion of a synchronous rectifier enhances overall efficiency.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 5V ~ 12V |
| Supplier Device Package | 16-SO |
| Synchronous Rectifier | Yes |
| Control Features | Current Limit, Frequency Control, Phase Control, Power Good, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 100% |
| Clock Sync | No |
| Number of Outputs | 1 |
