SD1433
RF TRANS NPN 16V M122Manufacturer: STMicroelectronics
Categories: Bipolar RF Transistors
Quality Control: Learn More
STMicroelectronics SD1433 is a high-power NPN bipolar RF transistor designed for demanding applications. This component delivers 58W of power with a collector current capability of 2.5A and a collector-emitter breakdown voltage of 16V. Featuring a minimum DC current gain of 10 at 1A and 5V, and a typical gain of 7dB, the SD1433 is well-suited for robust RF power amplification stages. Its robust construction includes a chassis, stud mount for efficient thermal management and operation at temperatures up to 200°C (TJ). The M122 package ensures reliable performance in industrial and high-power RF systems. This device is commonly utilized in broadcast transmitters, industrial heating equipment, and other high-frequency power applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | M122 |
| Mounting Type | Chassis, Stud Mount |
| Transistor Type | NPN |
| Operating Temperature | 200°C (TJ) |
| Gain | 7dB |
| Power - Max | 58W |
| Current - Collector (Ic) (Max) | 2.5A |
| Voltage - Collector Emitter Breakdown (Max) | 16V |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 10 @ 1A, 5V |
| Frequency - Transition | - |
| Noise Figure (dB Typ @ f) | - |
| Supplier Device Package | M122 |
