TDA7377
IC AMP CLASS AB DUAL/QUAD 35WManufacturer: STMicroelectronics
Categories: Audio Amplifiers
Quality Control: Learn More
STMicroelectronics TDA7377 is a versatile Class AB audio amplifier IC, configurable for either 2-channel stereo or 4-channel quad operation. This component delivers up to 35W per channel into a 4-ohm load, with a 10W per channel output into a 2-ohm load. Key integrated protection features include depop, short-circuit, and thermal protection, enhancing system reliability. The TDA7377 operates from an 8V to 18V supply voltage and is supplied in a tube package. It is commonly utilized in automotive audio systems and consumer electronics requiring robust and efficient audio amplification.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Depop, Short-Circuit and Thermal Protection, Standby |
| Packaging | Tube |
| Package / Case | - |
| Output Type | 2-Channel (Stereo) or 4-Channel (Quad) |
| Mounting Type | - |
| Type | Class AB |
| Operating Temperature | - |
| Voltage - Supply | 8V ~ 18V |
| Max Output Power x Channels @ Load | 35W x 2 @ 4Ohm; 10W x 4 @ 2Ohm |
| Supplier Device Package | - |
