TDA7297SA
IC AMP AB STEREO 10W 15CLIPWATTManufacturer: STMicroelectronics
Categories: Audio Amplifiers
Quality Control: Learn More
STMicroelectronics TDA7297SA is a 2-channel Class AB audio amplifier IC. This device delivers 10W per channel into an 8-ohm load, featuring a compact 15-Clipwatt package suitable for through-hole mounting. The TDA7297SA incorporates essential protection features including mute, short-circuit, and thermal shutdown, enhancing system reliability. Its standby mode further contributes to power efficiency. This component is commonly utilized in applications such as portable audio devices, multimedia systems, and automotive audio. The operating temperature range is 0°C to 70°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Mute, Short-Circuit and Thermal Protection, Standby |
| Packaging | Tube |
| Package / Case | Clipwatt-15 (Vertical, Bent and Staggered Leads) |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Through Hole |
| Type | Class AB |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 6.5V ~ 18V |
| Max Output Power x Channels @ Load | 10W x 2 @ 8Ohm |
| Supplier Device Package | 15-Clipwatt |
