TDA7297D13TR
IC AMP AB STEREO 10W POWERSO-20Manufacturer: STMicroelectronics
Categories: Audio Amplifiers
Quality Control: Learn More
STMicroelectronics TDA7297D13TR is a 2-channel stereo Class AB amplifier IC. This device delivers 10W per channel into an 8-ohm load, operating from a 6.5V to 18V supply range. The TDA7297D13TR features integrated mute and standby functions, along with robust short-circuit and thermal protection for reliable operation. Its PowerSO-20 package with an exposed pad facilitates efficient heat dissipation. This component is commonly found in consumer electronics, audio systems, and automotive applications. The TDA7297D13TR is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Mute, Short-Circuit and Thermal Protection, Standby |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.433"", 11.00mm Width) Exposed Pad |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Surface Mount |
| Type | Class AB |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 6.5V ~ 18V |
| Max Output Power x Channels @ Load | 10W x 2 @ 8Ohm |
| Supplier Device Package | PowerSO-20 |
