THG3809X
LED GREEN CLEAR T/HManufacturer: Stanley Electric Co
Categories: LED Indication - Discrete
Quality Control: Learn More
Stanley Electric Co. THG3809X is a through-hole mounted green LED, designed for discrete indication applications. This component features a clear, colorless lens with a round, flat-top profile, measuring 3mm (T-1) in diameter. Operating with a typical forward voltage of 3V, it achieves a luminous intensity of 180mcd at a test current of 5mA. The dominant wavelength is 525nm, with a peak wavelength of 520nm, providing a distinct green light output. The viewing angle is 90° for both horizontal and vertical planes. This component is commonly utilized in industrial automation, consumer electronics, and medical equipment for status indication and visual feedback. It is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 180mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3V |
| Lens Color | Colorless |
| Current - Test | 5mA |
| Viewing Angle | 90°, 90° |
| Height (Max) | 4.60mm |
| Wavelength - Peak | 520nm |
| Wavelength - Dominant | 525nm |
| Supplier Device Package | - |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 3mm, T-1 |
