DC5305S
LED BLUE-GRN CLEAR 5MM ROUND T/HManufacturer: Stanley Electric Co
Categories: LED Indication - Discrete
Quality Control: Learn More
Stanley Electric Co. DC5305S is a 5mm, through-hole, blue-green LED with a dominant wavelength of 505nm and a peak wavelength of 502nm. This discrete indicator features a clear, colorless lens with a domed top, providing a 30° viewing angle. Rated for 20mA, it achieves a typical forward voltage of 3.5V and a luminous intensity of 800mcd at the test current. The component is supplied in bulk packaging and is suitable for applications requiring precise visual feedback in industrial automation, consumer electronics, and medical equipment.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Blue-Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 800mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.5V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 30° |
| Height (Max) | 7.80mm |
| Wavelength - Peak | 502nm |
| Wavelength - Dominant | 505nm |
| Supplier Device Package | 5mm Round |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
