DB1113F-TR
LED BLUE DIFFUSED SMD R/AManufacturer: Stanley Electric Co
Categories: LED Indication - Discrete
Quality Control: Learn More
Stanley Electric Co 1113F series blue diffused SMD LED, part number DB1113F-TR. This discrete LED features a 470nm dominant wavelength with a typical forward voltage of 3.3V at 10mA test current, producing 14mcd luminous intensity. The component is housed in a 2-SMD, No Lead package with a surface mount, right-angle configuration. Its diffused lens, measuring 1.70mm x 0.60mm, is rectangular with a domed top, providing a wide 130° viewing angle. The overall dimensions are 2.10mm L x 1.00mm W x 0.70mm H (max). This component is supplied on tape and reel, suitable for applications in industrial automation, consumer electronics, and medical devices requiring clear visual indication.
Additional Information
Series: 1113FRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, No Lead |
| Color | Blue |
| Size / Dimension | 2.10mm L x 1.00mm W |
| Mounting Type | Surface Mount, Right Angle |
| Millicandela Rating | 14mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.3V |
| Lens Color | White |
| Current - Test | 10mA |
| Viewing Angle | 130° |
| Height (Max) | 0.70mm |
| Wavelength - Peak | 467nm |
| Wavelength - Dominant | 470nm |
| Supplier Device Package | SMD |
| Lens Transparency | Diffused |
| Lens Style | Rectangle with Domed Top |
| Lens Size | 1.70mm x 0.60mm |
