DB1111C-TR
LED BLUE DIFFUSED SMDManufacturer: Stanley Electric Co
Categories: LED Indication - Discrete
Quality Control: Learn More
Stanley Electric Co's 1111C series LED, part number DB1111C-TR, is a diffused blue surface-mount indicator. This 0603 (1608 Metric) package features a 1.60mm L x 0.80mm W footprint and a maximum height of 0.80mm. The component emits blue light with a dominant wavelength of 470nm and a peak wavelength of 467nm, providing a typical forward voltage of 3.3V at 10mA test current. The diffused lens, with a white lens color and a rectangular flat-top style, offers a wide 130° viewing angle, contributing to a millicandela rating of 14mcd. This component is commonly utilized in industrial automation, automotive lighting, and consumer electronics for status indication. The DB1111C-TR is supplied in Tape & Reel packaging.
Additional Information
Series: 1111CRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 0603 (1608 Metric) |
| Color | Blue |
| Size / Dimension | 1.60mm L x 0.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 14mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.3V |
| Lens Color | White |
| Current - Test | 10mA |
| Viewing Angle | 130° |
| Height (Max) | 0.80mm |
| Wavelength - Peak | 467nm |
| Wavelength - Dominant | 470nm |
| Supplier Device Package | SMD |
| Lens Transparency | Diffused |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.10mm x 0.80mm |
