NSR145B
DISP 7SEG 0.39"" OV/FL RED 10DIPManufacturer: Stanley Electric Co
Categories: LED Character and Numeric
Quality Control: Learn More
Stanley Electric Co. NSR145B is a 7-segment alphanumeric display module featuring a red LED character with an overflow capability. This component is designed for applications requiring clear numeric or symbolic representation. It operates with a typical forward voltage of 1.7V and a test current of 20mA, resulting in a millicandela rating of 6.4mcd. The digit size is 0.39 inches (10.00mm), and the module dimensions are 0.748" H x 0.492" W x 0.248" D (19.00mm x 12.50mm x 6.30mm). The NSR145B utilizes a universal common pin configuration and is packaged in a 10-DIP (0.600", 15.24mm) format. This component is commonly found in industrial control panels, test equipment, and general instrumentation.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 10-DIP (0.600"", 15.24mm) |
| Color | Red |
| Display Type | 7-Segment |
| Size / Dimension | 0.748"" H x 0.492"" W x 0.248"" D (19.00mm x 12.50mm x 6.30mm) |
| Number of Characters | +/-1 (overflow) |
| Millicandela Rating | 6.4mcd |
| Common Pin | Universal |
| Digit/Alpha Size | 0.39"" (10.00mm) |
| Voltage - Forward (Vf) (Typ) | 1.7V |
| Current - Test | 20mA |
| Wavelength - Peak | 660nm |
| Power Dissipation (Max) | 60mW |
