SKY13384-350LF
IC RF SWITCH SP4T 4GHZ 16QFNManufacturer: Skyworks Solutions Inc.
Categories: RF Switches
Quality Control: Learn More
Skyworks Solutions Inc. SKY13384-350LF is a General Purpose SP4T RF Switch IC designed for high-performance applications. This surface-mount component operates within a frequency range of 20MHz to 4GHz, featuring a 50 Ohm impedance. Key performance metrics include an IIP3 of 51dBm and a P1dB of 30dBm, indicating excellent linearity. Insertion loss at 4GHz is a low 1.2dB, with isolation of 36dB. The device supports a supply voltage range of 3V to 5V. The SKY13384-350LF is housed in a 16-QFN (3x3) package with an exposed pad, supplied on tape and reel. This absorptive switch topology is suitable for use in wireless infrastructure, mobile devices, and other demanding RF signal routing applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-WFQFN Exposed Pad |
| Impedance | 50Ohm |
| Mounting Type | Surface Mount |
| Circuit | SP4T |
| RF Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 5V |
| Insertion Loss | 1.2dB |
| Frequency Range | 20MHz ~ 4GHz |
| Topology | Absorptive |
| P1dB | 30dBm |
| Test Frequency | 4GHz |
| Isolation | 36dB |
| Supplier Device Package | 16-QFN (3x3) |
| IIP3 | 51dBm |
