HY19-12LF

RF DIR COUPLR 1.85-1.99GHZ 8SOIC

Manufacturer: Skyworks Solutions Inc.

Categories: RF Directional Coupler

Quality Control: Learn More

The Skyworks Solutions Inc. HY19-12LF is a general-purpose RF directional coupler operating within the 1.85GHz to 1.99GHz frequency range. This component, presented in an 8-SOIC package with a 0.154" (3.90mm) width, is designed for reliable signal coupling applications. It exhibits a maximum power handling capability of 4W, a typical insertion loss of 0.5dB, and an isolation of 20dB. The return loss is specified at 17dB. This device is commonly utilized in wireless infrastructure and cellular base station applications. It is supplied on tape and reel (TR).

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SOIC (0.154"", 3.90mm Width)
Frequency1.85GHz ~ 1.99GHz
Insertion Loss0.5dB
ApplicationsGeneral Purpose
Power - Max4W
Coupling Factor-
Coupler TypeStandard
Isolation20dB
Return Loss17dB
Supplier Device Package8-SOIC
