ACA1212P2
IC RF AMP CATV 1.2GHZ 16SOICManufacturer: Skyworks Solutions Inc.
Categories: RF Amplifiers
Quality Control: Learn More
Skyworks Solutions Inc. ACA1212P2 is a high-performance RF amplifier designed for Cable Television (CATV) applications. This surface-mount component operates at a frequency of 1.2GHz, with a typical gain of 10.9dB at 1.218GHz. It features a low noise figure of 4dB, crucial for maintaining signal integrity in demanding CATV infrastructure. The device requires a supply voltage of 12V and draws a current of 395mA. Packaged in a 16-SOIC-EP (Exposed Pad) configuration, it is supplied on tape and reel for automated assembly. This amplifier is integral to forward and return path signal amplification within CATV distribution networks, ensuring reliable broadband data and video transmission.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 1.2GHz |
| RF Type | CATV |
| Voltage - Supply | 12V |
| Gain | 10.9dB |
| Current - Supply | 395mA |
| Noise Figure | 4dB |
| P1dB | - |
| Test Frequency | 1.218GHz |
| Supplier Device Package | 16-SOIC-EP |
