SI8712AD-B-IM
DGTL ISO 5000VRMS 1CH GP 8LGAManufacturer: Skyworks Solutions Inc.
Categories: Digital Isolators
Quality Control: Learn More
Skyworks Solutions Inc. SI8712AD-B-IM is a single-channel digital isolator designed for robust signal isolation in demanding applications. This general-purpose isolator offers 5000Vrms of isolation voltage and utilizes capacitive coupling technology for reliable data transfer up to 15Mbps. Key performance metrics include a minimum common-mode transient immunity (CMTI) of 20kV/µs, ensuring signal integrity in noisy environments. The device features a propagation delay of 60ns (max) for both low-to-high and high-to-low transitions and a pulse width distortion of 20ns (max). Typical rise and fall times are 15ns and 5ns respectively. Operating over a temperature range of -40°C to 125°C, the SI8712AD-B-IM is housed in an 8-VELGA package suitable for surface mounting. It is commonly employed in industrial automation, power supplies, and medical equipment where high isolation is critical. The device operates from a supply voltage range of 3V to 30V.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 8-VELGA |
| Mounting Type | Surface Mount |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 3V ~ 30V |
| Data Rate | 15Mbps |
| Technology | Capacitive Coupling |
| Voltage - Isolation | 5000Vrms |
| Inputs - Side 1/Side 2 | 1/0 |
| Supplier Device Package | 8-LGA (10x12.5) |
| Rise / Fall Time (Typ) | 15ns, 5ns |
| Common Mode Transient Immunity (Min) | 20kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns |
| Isolated Power | No |
| Channel Type | Unidirectional |
| Pulse Width Distortion (Max) | 20ns |
| Number of Channels | 1 |
