SI8040AA-B-IUR
DGTL ISO 1000VRMS 4CH GP 16QSOPManufacturer: Skyworks Solutions Inc.
Categories: Digital Isolators
Quality Control: Learn More
General Purpose Digital Isolator 1000Vrms 4 Channel 10Mbps 35kV/µs CMTI 16-SSOP (0.154"", 3.90mm Width)
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 3.15V ~ 5.5V |
| Data Rate | 10Mbps |
| Technology | Capacitive Coupling |
| Voltage - Isolation | 1000Vrms |
| Inputs - Side 1/Side 2 | 4/0 |
| Supplier Device Package | 16-QSOP |
| Rise / Fall Time (Typ) | 2.5ns, 2.5ns |
| Common Mode Transient Immunity (Min) | 35kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 65ns, 65ns |
| Isolated Power | No |
| Channel Type | Unidirectional |
| Pulse Width Distortion (Max) | 30ns |
| Number of Channels | 4 |
Request a Quote
