SL38160CZC-XXXX
IC CLOCK 200MHZ 4PLL 16TSSOPManufacturer: Silicon Labs
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Silicon Labs SL38160CZC-XXXX is a single-circuit EProClock® series clock generator and frequency synthesizer. This device operates up to 200MHz and features a 1:5 ratio for input to output frequency division. It supports clock and crystal inputs, with clock outputs. The SL38160CZC-XXXX includes a PLL with bypass functionality and provides a divider/multiplier capability. Packaged in a 16-TSSOP (0.173", 4.40mm Width) for surface mounting, it operates within a voltage range of 2.25V to 3.63V and an ambient temperature range of 0°C to 70°C. This component is commonly found in networking, telecommunications, and consumer electronics applications. The device is supplied on Tape & Reel (TR).
Additional Information
Series: EProClock®RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 200MHz |
| Input | Clock, Crystal |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 2.25V ~ 3.63V |
| Ratio - Input:Output | 1:5 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 16-TSSOP |
| PLL | Yes with Bypass |
| Divider/Multiplier | Yes/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
