LH75410N0Q100C0
IC MCU 32BIT ROMLESS 144LQFPManufacturer: SHARP/Socle Technology
Categories: Microcontrollers
Quality Control: Learn More
The SHARP/Socle Technology LH75410N0Q100C0 is a 32-bit ARM7® BlueStreak ; LH7 microcontroller featuring a ROMless architecture. This single-core processor operates at 84MHz and offers 32KB x 8 of RAM. Connectivity options include EBI/EMI, SPI, SSI, SSP, and UART/USART. On-chip peripherals consist of A/D converters with 8x10-bit resolution, Brown-out Detect/Reset, DMA, LCD controller, POR, PWM, and WDT. With 76 I/O lines, it supports internal oscillators and is housed in a 144-LQFP package for surface mounting. The operating temperature range is -40°C to 85°C (TA), with a supply voltage of 1.7V to 3.6V. This component is commonly found in applications requiring advanced processing and flexible peripheral integration.
Additional Information
Series: BlueStreak ; LH7RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 84MHz |
| Program Memory Size | - |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | ARM7® |
| Data Converters | A/D 8x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.7V ~ 3.6V |
| Connectivity | EBI/EMI, SPI, SSI, SSP, UART/USART |
| Peripherals | Brown-out Detect/Reset, DMA, LCD, POR, PWM, WDT |
| Number of I/O | 76 |
| Programmable | Not Verified |
