GM5ZV01200A
LED AMBER CLEAR 6050 SMDManufacturer: Sharp Microelectronics
Categories: LED Indication - Discrete
Quality Control: Learn More
Sharp Microelectronics GM5ZV01200A is an amber LED with a dominant wavelength of 588nm and a peak wavelength of 591nm. This discrete indicator component is housed in a 6050 (4-SMD, Flat Leads) surface mount package, measuring 6.00mm L x 5.00mm W with a maximum height of 2.40mm. It features a clear, colorless lens with a round, flat top design and a lens diameter of 3.20mm. The GM5ZV01200A exhibits a typical forward voltage of 2.2V and a millicandela rating of 500mcd at a test current of 60mA. This component is commonly utilized in industrial automation, automotive lighting, and general indication applications. It is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-SMD, Flat Leads |
| Color | Amber |
| Size / Dimension | 6.00mm L x 5.00mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 500mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Colorless |
| Current - Test | 60mA |
| Viewing Angle | - |
| Height (Max) | 2.40mm |
| Wavelength - Peak | 591nm |
| Wavelength - Dominant | 588nm |
| Supplier Device Package | 6050 |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 3.20mm Dia |
