LS013B7DH06-DU
GRAPHIC DISPLAY TFT - 1.3Manufacturer: Sharp Microelectronics
Categories: LCD, OLED, Graphic
Quality Control: Learn More
The Sharp Microelectronics LS013B7DH06-DU is a 1.3-inch transflective TFT color graphic display module with a resolution of 128 x 128 pixels. Featuring a serial interface, this display offers a compact 23.81mm x 23.81mm viewing area. Its transflective nature allows for operation in both bright ambient light conditions and with its own illumination, providing flexibility for various environments. This component is suitable for applications demanding clear graphical representation in portable electronics, industrial control panels, and medical devices. The module is supplied in tray packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Display Type | TFT - Color |
| Display Mode | Transflective |
| Backlight | Without Backlight |
| Interface | Serial |
| Viewing Area | 23.81mm W x 23.81mm H |
| Dot Pixels | 128 x 128 |
| Diagonal Screen Size | 1.3"" (33.02mm) |
| Background Color | - |
| Graphics Color | - |
| Touchscreen | - |
