PQ1CG3032FZH
IC REG BUCK ADJ 3.5A TO220-5Manufacturer: Sharp Microelectronics
Categories: DC DC Switching Regulators
Quality Control: Learn More
Sharp Microelectronics PQ1CG3032FZH is a buck switching regulator IC designed for efficient step-down voltage conversion. This adjustable positive or negative output regulator provides a robust 3.5A output current, with an adjustable output voltage range from ±1.26V up to ±30V or 35V, depending on the configuration.
Operating at a switching frequency of 150kHz, the PQ1CG3032FZH utilizes a non-synchronous buck topology. It supports input voltages from 8V to 35V and is housed in a TO-220-5 formed leads package suitable for through-hole mounting. The operating temperature range is -20°C to 80°C (TA). This component is commonly employed in industrial power supplies, automotive electronics, and consumer electronics applications requiring precise and efficient DC-DC conversion.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-220-5 Formed Leads |
| Output Type | Adjustable |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 3.5A |
| Operating Temperature | -20°C ~ 80°C (TA) |
| Output Configuration | Positive or Negative |
| Frequency - Switching | 150kHz |
| Voltage - Input (Max) | 35V |
| Topology | Buck |
| Supplier Device Package | TO-220-5 |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 35V, -30V |
| Voltage - Input (Min) | 8V |
| Voltage - Output (Min/Fixed) | ±1.26V |
