SAWW9H0A-U3V2-HA
LED ACRICH WARM WHT 2700K SMDManufacturer: Seoul Semiconductor Inc.
Categories: LED White Lighting
Quality Control: Learn More
LED Lighting Acrich White, Warm 2700K 64V 20mA 125° 1616 (4040 Metric)
Additional Information
Series: AcrichRoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1616 (4040 Metric) |
| Color | White, Warm |
| Size / Dimension | 0.157"" L x 0.157"" W (4.00mm x 4.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 64V |
| Current - Test | 20mA |
| Viewing Angle | 125° |
| Current - Max | 30mA |
| Supplier Device Package | - |
| Lumens/Watt @ Current - Test | 103 lm/W |
| Height - Seated (Max) | 0.087"" (2.20mm) |
| CCT (K) | 2700K |
| CRI (Color Rendering Index) | 80 |
| Flux @ 25°C, Current - Test | 132lm (109lm ~ 154lm) |
| Flux @ 85°C, Current - Test | - |
