SDP1108-R
SENSOR 0.073PSID 0.2"" 4V MODULEManufacturer: Sensirion AG
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Pressure Sensor 0.07PSI (0.5kPa) Differential Male - 0.2"" (5.2mm) Tube, Dual 0.25 V ~ 4 V Module
Additional Information
Series: SDPx108RoHS Status: ROHS3 CompliantManufacturer Lead Time: 9 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tray |
| Package / Case | Module |
| Output Type | Analog Voltage |
| Output | 0.25 V ~ 4 V |
| Operating Pressure | 0.07PSI (0.5kPa) |
| Pressure Type | Differential |
| Accuracy | ±0.4% |
| Operating Temperature | -40°C ~ 80°C |
| Termination Style | - |
| Voltage - Supply | 5V |
| Port Size | Male - 0.2"" (5.2mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | Module |
| Port Style | Barbed |
| Maximum Pressure | 14.5PSI (100kPa) |
