CYNB25-1200
SCR 1.2KV 25A TO220ABManufacturer: Sensata-Crydom
Categories: SCRs
Quality Control: Learn More
Sensata-Crydom CYNB25-1200 is a standard recovery Silicon Controlled Rectifier (SCR) designed for high-voltage power control applications. This through-hole component features a 1.2 kV blocking voltage and a 25 A RMS on-state current rating. The TO-220AB package offers robust thermal performance, suitable for operation from -40°C to 125°C. Key parameters include a maximum on-state voltage (Vtm) of 1.6 V and a gate trigger current (Igt) of 40 mA. Non-repetitive surge current handling is rated at 320 A (50 Hz) and 350 A (60 Hz). This device finds utility in industrial power supplies, motor control, and lighting control systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-3 |
| Mounting Type | Through Hole |
| SCR Type | Standard Recovery |
| Operating Temperature | -40°C ~ 125°C |
| Current - Hold (Ih) (Max) | 50 mA |
| Current - Gate Trigger (Igt) (Max) | 40 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 320A, 350A |
| Current - On State (It (AV)) (Max) | 16 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V |
| Voltage - On State (Vtm) (Max) | 1.6 V |
| Current - Off State (Max) | 5 µA |
| Supplier Device Package | TO-220AB |
| Current - On State (It (RMS)) (Max) | 25 A |
| Voltage - Off State | 1.2 kV |
