M5060THC800
DIODE MODULE GP 800V 60AManufacturer: Sensata-Crydom
Categories: Diode Arrays
Quality Control: Learn More
Sensata-Crydom M5060THC800 is a robust diode module featuring three common cathode configurations. This component offers a maximum DC reverse voltage (Vr) of 800 V and an average rectified current (Io) of 60 A per diode. The forward voltage (Vf) is rated at a maximum of 1.35 V at 60 A. Designed for standard recovery speeds exceeding 500 ns, the M5060THC800 utilizes a chassis mount design for efficient thermal management. Operating within a junction temperature range of -40°C to 125°C, this module is suitable for demanding applications in industrial power supplies, motor control, and power factor correction systems. The technology employed ensures reliable performance in high-power rectification scenarios.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Diode Configuration | 3 Common Cathode |
| Current - Average Rectified (Io) (per Diode) | 60A |
| Supplier Device Package | Module |
| Operating Temperature - Junction | -40°C ~ 125°C |
| Voltage - DC Reverse (Vr) (Max) | 800 V |
| Voltage - Forward (Vf) (Max) @ If | 1.35 V @ 60 A |
