F18107RD1200
DIODE MODULE GP 1200V 105AManufacturer: Sensata-Crydom
Categories: Diode Arrays
Quality Control: Learn More
Sensata-Crydom F18 Series Diode Module, part number F18107RD1200, is a robust power semiconductor solution. This module features a standard recovery diode configuration, specified with a maximum repetitive peak reverse voltage of 1200V and a continuous average forward current rating of 105A. The diode array is arranged in a single pair, series connection, suitable for high-power applications. It exhibits a forward voltage drop of 1.65V at a forward current of 300A. Designed for chassis mounting, this module is packaged in Bulk for efficient integration into industrial control systems, power supplies, and renewable energy applications. Its standard recovery speed is greater than 500ns.
Additional Information
Series: F18RoHS Status: RoHS CompliantManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 105A (DC) |
| Supplier Device Package | - |
| Voltage - DC Reverse (Vr) (Max) | 1200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.65 V @ 300 A |
