3-119-054
NEMA 5-15R WITH WALLManufacturer: SCHURTER Inc.
Categories: Plugs and Receptacles
Quality Control: Learn More
Power Connector Receptacle, Female Sockets NEMA 5-15R Panel Mount, Snap-In
Additional Information
Series: NR021RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Voltage Rating | 125VAC |
| Current Rating (Amps) | 15A |
| Mounting Type | Panel Mount, Snap-In |
| Number of Positions | 3 |
| Termination | Solder Eyelet |
| Approval Agency | CSA, cULus, UL |
| Ingress Protection | IP20 |
| Panel Thickness | 0.031"" ~ 0.063"" (0.79mm ~ 1.60mm) |
| Panel Cutout Dimensions | Variable Size |
| Connector Style | NEMA 5-15R |
| Material Flammability Rating | UL94 V-0 |
