SanRex Corporation TG40E60 is a standard TRIAC designed for high-power switching applications. This component features an RMS on-state current rating of 40 A and an off-state voltage of 600 V. The TG40E60 requires a maximum gate trigger current of 50 mA and a gate trigger voltage of 1.5 V for activation. It exhibits a non-repetitive surge current capability of 420 A at 60 Hz. With a chassis mount package, this TRIAC is suitable for industrial control, power supplies, and HVAC systems. The operating temperature range is -40°C to 125°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Triac Type | Standard |
| Configuration | Single |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Current - Hold (Ih) (Max) | 30 mA |
| Current - Gate Trigger (Igt) (Max) | 50 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 420A @ 60Hz |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5 V |
| Supplier Device Package | - |
| Current - On State (It (RMS)) (Max) | 40 A |
| Voltage - Off State | 600 V |
