DD200KB80
DIODE MODULE GP 800V 200AManufacturer: SanRex Corporation
Categories: Diode Arrays
Quality Control: Learn More
SanRex Corporation DD200KB80 is a diode module featuring a single pair of diodes connected in series. This component offers a maximum DC reverse voltage (Vr) of 800 V and an average rectified current (Io) of 200 A per diode. The forward voltage drop (Vf) is a maximum of 1.3 V at a forward current (If) of 620 A. Reverse leakage current is specified at 50 mA at 800 V. The DD200KB80 utilizes standard recovery technology with a speed characteristic of >500ns for currents greater than 200mA. Mounting is via chassis mount, and the component is supplied in tray packaging. This diode module is suitable for applications in industrial power supplies, motor drives, and welding equipment. The operating junction temperature range is -40°C to 150°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 200A |
| Supplier Device Package | - |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 800 V |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 620 A |
| Current - Reverse Leakage @ Vr | 50 mA @ 800 V |
