DCA200DB220
DIODE MODULE GP 2200V 200AManufacturer: SanRex Corporation
Categories: Diode Arrays
Quality Control: Learn More
SanRex Corporation DCA200DB220 is a high-power diode module featuring a 1 pair series connection configuration. This chassis mount device offers a maximum DC reverse voltage (Vr) of 2200 V and an average rectified current (Io) of 200A per diode. The forward voltage (Vf) is rated at a maximum of 1.4 V at 620 A. Reverse leakage current is specified at 50 mA at 2200 V. Operating junction temperatures range from -40°C to 150°C. The module utilizes standard recovery technology with speeds greater than 500 ns for currents exceeding 200 mA. This component is commonly employed in industrial power conversion, motor control, and high-voltage power supply applications. The product is supplied in Tray packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Diode Configuration | 1 Pair Series Connection |
| Current - Average Rectified (Io) (per Diode) | 200A |
| Supplier Device Package | - |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 2200 V |
| Voltage - Forward (Vf) (Max) @ If | 1.4 V @ 620 A |
| Current - Reverse Leakage @ Vr | 50 mA @ 2200 V |
