SCP9VT78HPL1VLS06E
LED LM101A WARM WHT 3000K SMDManufacturer: Samsung Semiconductor, Inc.
Categories: LED White Lighting
Quality Control: Learn More
Samsung Semiconductor, Inc. presents the LM101A series LED, part number SCP9VT78HPL1VLS06E. This warm white LED features a correlated color temperature of 3000K, specified within a 5-step MacAdam ellipse for consistent color quality. Designed for surface mounting, it utilizes a 0505 (1313 Metric) package with dimensions of 1.18mm x 1.18mm. The typical forward voltage is 2.9V, with a test current of 150mA delivering 41 lumens and 94 lm/W. The maximum drive current is 450mA. This component offers a wide viewing angle of 150° and a high Color Rendering Index (CRI) of 90, making it suitable for applications in general lighting and display backlighting. The SCP9VT78HPL1VLS06E is supplied on tape and reel.
Additional Information
Series: LM101ARoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0505 (1313 Metric) |
| Color | White, Warm |
| Size / Dimension | 0.046"" L x 0.046"" W (1.18mm x 1.18mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.9V |
| Current - Test | 150mA |
| Viewing Angle | 150° |
| Current - Max | 450mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 94 lm/W |
| Height - Seated (Max) | 0.017"" (0.42mm) |
| CCT (K) | 3000K 5-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 90 |
| Flux @ 25°C, Current - Test | - |
| Flux @ 85°C, Current - Test | 41lm (35lm ~ 47lm) |
