SCA7RT78HAL9RTAJEP
LED LH309A COOL WHT 5000K 12CSPManufacturer: Samsung Semiconductor, Inc.
Categories: LED White Lighting
Quality Control: Learn More
Samsung Semiconductor, Inc. LH309A series Cool White LED, part number SCA7RT78HAL9RTAJEP. This 2020 (5050 Metric) package LED features a Color Temperature of 5000K and a broad 120° viewing angle. Designed for surface mounting with a 12-CSP package, this component operates at a typical forward voltage of 26V and a test current of 150mA, capable of handling up to 250mA. At 150mA test current and 85°C, it delivers 568 lumens with a luminous efficacy of 146 lm/W, and a CRI of 70. The low profile height of 0.016" (0.40mm) and dimensions of 0.197" x 0.197" (5.00mm x 5.00mm) make it suitable for applications in general lighting and display backlighting. Supplied in Tape & Reel packaging.
Additional Information
Series: LH309ARoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2020 (5050 Metric) |
| Color | White, Cool |
| Size / Dimension | 0.197"" L x 0.197"" W (5.00mm x 5.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 26V |
| Current - Test | 150mA |
| Viewing Angle | 120° |
| Current - Max | 250mA |
| Supplier Device Package | 12-CSP |
| Lumens/Watt @ Current - Test | 146 lm/W |
| Height - Seated (Max) | 0.016"" (0.40mm) |
| CCT (K) | 5000K |
| CRI (Color Rendering Index) | 70 |
| Flux @ 25°C, Current - Test | - |
| Flux @ 85°C, Current - Test | 568lm (510lm ~ 625lm) |
