SL-B8U7N90L1WW
LED MOD INFLUXL09 LNR STR 3500KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. inFlux_L09 series SL-B8U7N90L1WW is a linear LED module designed for high-performance lighting applications. This warm white module operates at a correlated color temperature (CCT) of 3500K, delivering a typical luminous flux of 8530lm at a test current of 1.38A. With a high efficacy of 128 lm/W, it is suitable for demanding illumination tasks. The module features a CRI of 80 and a wide 115° viewing angle. Its compact dimensions of 559.50mm L x 39.60mm W and a height of 5.90mm, along with integrated connector features, facilitate straightforward integration into luminaire designs. This component is well-suited for architectural lighting, retail environments, and general illumination where efficient and high-quality light output is paramount. The SL-B8U7N90L1WW is supplied in tray packaging.
Additional Information
Series: inFlux_L09RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 559.50mm L x 39.60mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 48.2V |
| Height | 5.90mm |
| Current - Test | 1.38A |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 1.38A |
| Lumens/Watt @ Current - Test | 128 lm/W |
| CCT (K) | 3500K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 65°C |
| Luminous Flux @ Current/Temperature | 8530lm (Typ) |
