SL-B8U4N80L1WW
LED MOD INFLUXS04 LNR STR 3500KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. SL-B8U4N80L1WW is a high-performance LED module from the inFlux_S04 series, configured as a linear light strip. This warm white module operates at a Correlated Color Temperature (CCT) of 3500K with a Color Rendering Index (CRI) of 80, delivering a typical luminous flux of 4265 lumens at 24.1V forward voltage. Optimized for efficiency, it achieves 128 lumens per watt at a test current of 1.38A, with a maximum current rating of 1.38A. The module features a flat lens type and a broad 115° viewing angle. Its dimensions are 279.60mm in length and 39.60mm in width, with a height of 5.90mm. This component is suitable for general lighting applications, including commercial and architectural lighting. The SL-B8U4N80L1WW is supplied in trays and includes an integrated connector for ease of installation.
Additional Information
Series: inFlux_S04RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 279.60mm L x 39.60mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 24.1V |
| Height | 5.90mm |
| Current - Test | 1.38A |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 1.38A |
| Lumens/Watt @ Current - Test | 128 lm/W |
| CCT (K) | 3500K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 65°C |
| Luminous Flux @ Current/Temperature | 4265lm (Typ) |
