SL-B8U3N80L1WW
LED MOD INFLUXL04 LNR STR 3500KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. inFlux_L04 series LED module, part number SL-B8U3N80L1WW, offers a linear light strip configuration with a warm white color temperature of 3500K. Engineered for high-efficacy lighting applications, this module delivers a typical luminous flux of 4260 lumens at a test current of 1.38A, achieving 128 lumens per watt. It features a 24.1V forward voltage and an 80 CRI for accurate color rendering. The module's dimensions are 559.50mm in length and 23.70mm in width, with a height of 5.90mm. The flat lens design and a 115° viewing angle are optimized for uniform light distribution. This component is suitable for general illumination, architectural lighting, and display applications. Packaging is provided in trays.
Additional Information
Series: inFlux_L04RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 559.50mm L x 23.70mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 24.1V |
| Height | 5.90mm |
| Current - Test | 1.38A |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 1.38A |
| Lumens/Watt @ Current - Test | 128 lm/W |
| CCT (K) | 3500K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 65°C |
| Luminous Flux @ Current/Temperature | 4260lm (Typ) |
