SL-B8R2N60L1WW
LED MOD INFLUXL03 LNR STR 5000KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. inFlux_L03 series LED module, part number SL-B8R2N60L1WW, offers a cool white linear light strip configuration with a correlated color temperature (CCT) of 5000K. This LED module operates at a typical forward voltage of 18.1V and a maximum current of 1.15A, achieving 141 lm/W at this test current. The luminous flux is typically 2930 lumens at a test temperature of 65°C. Featuring a flat lens type and a 115° viewing angle, this module has dimensions of 559.50mm in length and 23.70mm in width, with a height of 5.90mm. It includes an integrated connector for ease of use. The SL-B8R2N60L1WW is suitable for general lighting applications, including commercial and architectural lighting. This component is supplied in trays.
Additional Information
Series: inFlux_L03RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Cool |
| Wavelength | - |
| Size / Dimension | 559.50mm L x 23.70mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 18.1V |
| Height | 5.90mm |
| Current - Test | 1.15A |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 1.15A |
| Lumens/Watt @ Current - Test | 141 lm/W |
| CCT (K) | 5000K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 65°C |
| Luminous Flux @ Current/Temperature | 2930lm (Typ) |
