SL-B8R1N40L1WW
LED MOD INFLUXS02 LNR STR 5000KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. SL-B8R1N40L1WW is a cool white linear LED module from the inFlux_S02 series, featuring a color temperature of 5000K and a CRI of 80. This module delivers a typical luminous flux of 2345 lumens at a test current of 1.38A, achieving an efficacy of 140 lm/W. Operating at a forward voltage of 12.1V, it is designed for efficient illumination. The module has a flat lens type and a wide 115° viewing angle. Its dimensions are 280.00mm in length and 24.00mm in width, with a height of 5.90mm. This component is supplied in trays and includes an integrated connector for ease of use. Applications include general lighting, architectural lighting, and task lighting systems.
Additional Information
Series: inFlux_S02RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Cool |
| Wavelength | - |
| Size / Dimension | 280.00mm L x 24.00mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 12.1V |
| Height | 5.90mm |
| Current - Test | 1.38A |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 1.38A |
| Lumens/Watt @ Current - Test | 140 lm/W |
| CCT (K) | 5000K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 65°C |
| Luminous Flux @ Current/Temperature | 2345lm (Typ) |
