SI-B9V151560WW
LED MOD LT-M562G LNR STRP 3000KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. presents the LT-M562G series LED module, part number SI-B9V151560WW. This warm white linear light strip offers a correlated color temperature (CCT) of 3000K, specified within a 3-step MacAdam ellipse for consistent color uniformity. With a high Color Rendering Index (CRI) of 90, it accurately reproduces colors, making it suitable for applications demanding precise color rendition. The module operates at a maximum current of 600mA, achieving a typical luminous flux of 1380 lumens and a luminous efficacy of 93 lm/W at the test current of 600mA and 50°C. Its dimensions are 560.00mm in length and 18.00mm in width, with a height of 5.80mm. The viewing angle is 115°, and the forward voltage is typically 24.7V. This component is commonly found in architectural lighting, retail display lighting, and general illumination sectors. It is supplied in trays.
Additional Information
Series: LT-M562GRoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 560.00mm L x 18.00mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 24.7V |
| Height | 5.80mm |
| Current - Test | 600mA |
| Viewing Angle | 115° |
| Lens Type | Flat |
| Current - Max | 600mA |
| Lumens/Watt @ Current - Test | 93 lm/W |
| CCT (K) | 3000K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 90 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 50°C |
| Luminous Flux @ Current/Temperature | 1380lm (Typ) |
