SI-B8T06128CWW
LED MOD LT-V282A LNR STRP 4000KManufacturer: Samsung Semiconductor, Inc.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Samsung Semiconductor, Inc. presents the SI-B8T06128CWW, a linear LED module from the LT-V282A series. This neutral white lighting component operates at a correlated color temperature (CCT) of 4000K, specified to a 3-step MacAdam ellipse for consistent color. Featuring a high luminous efficacy of 136 lm/W at 450mA test current, it delivers a typical luminous flux of 769lm. The module is configured as a linear light strip with dimensions of 275.00mm L x 18.00mm W and a height of 5.50mm. It includes an integrated connector for simplified integration and has a broad 120° viewing angle. The forward voltage is typically 12.6V at 450mA, with a maximum rated current of 540mA. The Color Rendering Index (CRI) is 80. This component is suitable for applications in general lighting and architectural lighting. It is supplied in a tray package.
Additional Information
Series: LT-V282ARoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Neutral |
| Wavelength | - |
| Size / Dimension | 275.00mm L x 18.00mm W |
| Type | LED Module |
| Configuration | Linear Light Strip |
| Voltage - Forward (Vf) (Typ) | 12.6V |
| Height | 5.50mm |
| Current - Test | 450mA |
| Viewing Angle | 120° |
| Lens Type | Flat |
| Current - Max | 540mA |
| Lumens/Watt @ Current - Test | 136 lm/W |
| CCT (K) | 4000K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 50°C |
| Luminous Flux @ Current/Temperature | 769lm (Typ) |
