RGTH60TS65DGC11
IGBT TRNCH FIELD 650V 58A TO247NManufacturer: Rohm Semiconductor
Categories: Single IGBTs
Quality Control: Learn More
Rohm Semiconductor RGTH60TS65DGC11 is a Trench Field Stop Insulated Gate Bipolar Transistor (IGBT) designed for high-voltage switching applications. This component offers a 650 V collector-emitter breakdown voltage and a continuous collector current capability of 58 A, with a pulsed current rating of 120 A. It features a low collector-emitter saturation voltage (Vce(on)) of 2.1 V at 15 V gate-emitter voltage and 30 A collector current. The device exhibits typical turn-on delay (Td(on)) of 27 ns and turn-off delay (Td(off)) of 105 ns at 25°C, with a specified reverse recovery time (trr) of 58 ns. With a maximum power dissipation of 194 W and an operating temperature range of -40°C to 175°C, the RGTH60TS65DGC11 is suitable for use in power factor correction, motor drives, and uninterruptible power supplies. It is packaged in a TO-247N (TO-247-3) through-hole configuration and supplied in tubes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 22 week(s)Product Status: Not For New DesignsPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Input Type | Standard |
| Reverse Recovery Time (trr) | 58 ns |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 30A |
| Supplier Device Package | TO-247N |
| IGBT Type | Trench Field Stop |
| Td (on/off) @ 25°C | 27ns/105ns |
| Switching Energy | - |
| Test Condition | 400V, 30A, 10Ohm, 15V |
| Gate Charge | 58 nC |
| Current - Collector (Ic) (Max) | 58 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector Pulsed (Icm) | 120 A |
| Power - Max | 194 W |
