2SK2731T146
MOSFET N-CH 30V 200MA SMT3Manufacturer: Rohm Semiconductor
Categories: Single FETs, MOSFETs
Quality Control: Learn More
Rohm Semiconductor's 2SK2731T146 is an N-Channel MOSFET designed for surface mount applications. This device features a Drain-to-Source Voltage (Vdss) of 30V and a continuous Drain current (Id) of 200mA at 25°C, with a maximum power dissipation of 200mW (Ta). The Rds On is specified at a maximum of 2.8 Ohms at 100mA and 10V Vgs. Gate-to-Source voltage limits are ±20V, and the threshold voltage (Vgs(th)) is 2.5V at 1mA. Input capacitance (Ciss) is a maximum of 25pF at 10V. Operating temperature range extends to 150°C (TJ). This component is supplied in a TO-236-3, SC-59, SOT-23-3 package, also known as SMT3, and is available on tape and reel. Its specifications make it suitable for use in various electronic systems, including consumer electronics and industrial control applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 200mA (Ta) |
| Rds On (Max) @ Id, Vgs | 2.8Ohm @ 100mA, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 200mW (Ta) |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Supplier Device Package | SMT3 |
| Drive Voltage (Max Rds On, Min Rds On) | 4V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 30 V |
| Input Capacitance (Ciss) (Max) @ Vds | 25 pF @ 10 V |
