RR601B4STL
DIODE GEN PURP 400V 2A DO214AAManufacturer: Rohm Semiconductor
Categories: Single Diodes
Quality Control: Learn More
Rohm Semiconductor RR601B4STL is a general-purpose rectifier diode designed for various electronic applications. This component features a 400V reverse voltage rating and a 2A average rectified forward current capability. It exhibits a low forward voltage drop of 1.15V at 2A and a reverse leakage of 10 µA at 400V. The diode operates across a junction temperature range of -55°C to 150°C. Its standard recovery speed, characterized by a reverse recovery time of 2 µs, makes it suitable for power supply circuits, switching power supplies, and general rectification tasks in consumer electronics and industrial automation. The component is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | - |
| Mounting Type | - |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 2 µs |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 2A |
| Supplier Device Package | - |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 400 V |
| Voltage - Forward (Vf) (Max) @ If | 1.15 V @ 2 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 400 V |
