1SS244T-77
DIODE GEN PURP 220V 200MA MSDManufacturer: Rohm Semiconductor
Categories: Single Diodes
Quality Control: Learn More
The Rohm Semiconductor 1SS244T-77 is a general-purpose diode designed for applications requiring reliable rectification. This component features a maximum reverse voltage (Vr) of 220 V and an average rectified current (Io) of 200 mA. With a forward voltage (Vf) of 1.5 V at 200 mA, it offers efficient operation. The diode exhibits a low reverse leakage current of 10 µA at its maximum rated Vr. Its axial leaded package, identified as DO-204AG or DO-34, facilitates through-hole mounting. The 1SS244T-77 has a specified reverse recovery time (trr) of 75 ns and a junction operating temperature up to 175°C, making it suitable for various industrial and consumer electronics applications. This device is supplied in Tape & Box (TB) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Box (TB)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Box (TB) |
| Package / Case | DO-204AG, DO-34, Axial |
| Mounting Type | Through Hole |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 75 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 3pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 200mA |
| Supplier Device Package | MSD |
| Operating Temperature - Junction | 175°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 220 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 200 mA |
| Current - Reverse Leakage @ Vr | 10 µA @ 220 V |
