2SA1579T106R
TRANS PNP 120V 0.05A UMT3Manufacturer: Rohm Semiconductor
Categories: Single Bipolar Transistors
Quality Control: Learn More
The Rohm Semiconductor 2SA1579T106R is a PNP bipolar junction transistor designed for surface mount applications. Featuring a collector-emitter breakdown voltage of 120V and a continuous collector current capability of 50mA, this component offers a transition frequency of 140MHz. It is supplied in an UMT3 package with a maximum power dissipation of 200mW and an operating junction temperature of 150°C. The device exhibits a minimum DC current gain (hFE) of 180 at 2mA collector current and 6V collector-emitter voltage. Typical applications for this transistor include general-purpose amplification and switching circuits, often found in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Transistor Type | PNP |
| Operating Temperature | 150°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 1mA, 10mA |
| Current - Collector Cutoff (Max) | 500nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 180 @ 2mA, 6V |
| Frequency - Transition | 140MHz |
| Supplier Device Package | UMT3 |
| Current - Collector (Ic) (Max) | 50 mA |
| Voltage - Collector Emitter Breakdown (Max) | 120 V |
| Power - Max | 200 mW |
