BD8LD650EFV-CE2
AUTOMOTIVE 8CH LOW SIDE SWITCH:Manufacturer: Rohm Semiconductor
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:8 N-Channel 500mA, 1A 20-HTSSOP-B
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Slew Rate Controlled |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-VSSOP (0.173"", 4.40mm Width) Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 8 |
| Interface | SPI |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Low Side |
| Rds On (Typ) | 650mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 4V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Current - Output (Max) | 500mA, 1A |
| Ratio - Input:Output | 1:8 |
| Supplier Device Package | 20-HTSSOP-B |
| Fault Protection | Current Limiting (Fixed), Over Temperature |
| Grade | Automotive |
| Qualification | AEC-Q100 |
