BD63510EFV-E2
IC MTR DRV BIPOLR 8-28V 28HTSSOPManufacturer: Rohm Semiconductor
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The Rohm Semiconductor BD63510EFV-E2 is a bipolar stepper motor driver featuring DMOS parallel technology. This highly integrated component incorporates both control and power stages, simplifying system design for applications requiring precise motor control. It supports a wide operating voltage range of 8V to 28V for both supply and load, with a 1A continuous output current. The device offers flexible step resolutions including 1, 1/2, 1/4, and 1/16 steps, enabling smooth and accurate motor operation. Housed in a 28-HTSSOP-B package with an exposed pad for enhanced thermal performance, the BD63510EFV-E2 is suitable for surface mounting. Its four half-bridge output configurations cater to bipolar stepper motor requirements. This driver is commonly utilized in industrial automation, robotics, and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-VSSOP (0.173"", 4.40mm Width) Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1A |
| Interface | Parallel |
| Operating Temperature | -25°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 8V ~ 28V |
| Applications | General Purpose |
| Technology | DMOS |
| Voltage - Load | 8V ~ 28V |
| Supplier Device Package | 28-HTSSOP-B |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
| Step Resolution | 1, 1/2, 1/4, 1/16 |
