BR93C76-WMN6TP
IC EEPROM 8KBIT SPI 2MHZ 8SOManufacturer: Rohm Semiconductor
Categories: Memory
Quality Control: Learn More
Rohm Semiconductor's BR93C76-WMN6TP is an 8Kbit non-volatile EEPROM memory IC with a Microwire interface. This component offers a 1K x 8 memory organization and operates at a 2 MHz clock frequency. Designed for surface mount applications, it is housed in an 8-SOIC package with a 3.90mm width, supplied on tape and reel. The BR93C76-WMN6TP supports a wide supply voltage range of 2.5V to 5.5V and features a word/page write cycle time of 5ms. Its operating temperature range is -40°C to 85°C. This memory solution is suitable for applications in industrial control, automotive systems, and consumer electronics where reliable data storage is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | 8Kbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.5V ~ 5.5V |
| Technology | EEPROM |
| Clock Frequency | 2 MHz |
| Memory Format | EEPROM |
| Supplier Device Package | 8-SOP |
| Write Cycle Time - Word, Page | 5ms |
| Memory Interface | Microwire |
| Memory Organization | 1K x 8 |
| Programmable | Not Verified |
