BA17812FP
IC REG LINEAR 12V 1A TO252-3Manufacturer: Rohm Semiconductor
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Rohm Semiconductor BA17812FP is a positive fixed linear voltage regulator IC designed for reliable power management. This component delivers a stable 12V output with a maximum current capability of 1A. Featuring a low quiescent current of 4.5mA and a maximum supply current of 6mA, it is suitable for various electronic applications. The device operates within a temperature range of -40°C to 85°C and supports input voltages up to 27V. The BA17812FP exhibits a typical dropout voltage of 2V at 1A, with a power supply rejection ratio (PSRR) of 63dB at 120Hz. It is supplied in a TO-252-3 (DPAK) surface-mount package, commonly utilized in industrial control, consumer electronics, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 4.5 mA |
| Voltage - Input (Max) | 27V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-252-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 12V |
| Control Features | - |
| PSRR | 63dB (120Hz) |
| Voltage Dropout (Max) | 2V @ 1A (Typ) |
| Protection Features | - |
| Current - Supply (Max) | 6 mA |
