SMLK18WBJCW
LED SML COOL WHITE 8000K 1808Manufacturer: Rohm Semiconductor
Categories: LED White Lighting
Quality Control: Learn More
Rohm Semiconductor SML Series LED, part number SMLK18WBJCW, offers a cool white illumination with a Correlated Color Temperature (CCT) of 8000K. This surface-mount component is housed in an 1808 (4520) package, measuring 4.00mm x 2.00mm with a maximum seated height of 0.70mm. It operates with a typical forward voltage of 3.9V and a test current of 90mA, delivering a typical luminous flux of 21 lumens. The maximum continuous forward current is rated at 150mA, with a lumens per watt efficiency of 60 lm/W at the test current. The 2-SMD, flat leads facilitate efficient assembly. This LED is commonly utilized in automotive lighting, general illumination, and display backlighting applications. Supplied in Tape & Reel (TR) packaging.
Additional Information
Series: SMLRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Flat Leads |
| Color | White, Cool |
| Size / Dimension | 0.157"" L x 0.079"" W (4.00mm x 2.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.9V |
| Current - Test | 90mA |
| Viewing Angle | - |
| Current - Max | 150mA |
| Supplier Device Package | 1808 (4520) |
| Lumens/Watt @ Current - Test | 60 lm/W |
| Height - Seated (Max) | 0.028"" (0.70mm) |
| CCT (K) | 8000K |
| CRI (Color Rendering Index) | - |
| Flux @ 25°C, Current - Test | 21lm (Typ) |
| Flux @ 85°C, Current - Test | - |
