SMLE12BC7TT86
LED BLUE CLEAR 1608 SMDManufacturer: Rohm Semiconductor
Categories: LED Indication - Discrete
Quality Control: Learn More
The Rohm Semiconductor EXCELED™ SMLE12BC7TT86 is a discrete surface mount LED designed for indication applications. This component features a blue emission with a dominant wavelength of 470nm. It operates with a typical forward voltage of 2.9V and is rated at 22mcd at a test current of 5mA. The LED is housed in a compact 0603 (1608 Metric) package with dimensions of 1.60mm x 0.80mm. It has a clear, colorless lens with a flat top rectangular style, measuring 1.20mm x 0.80mm. The SMLE12BC7TT86 is supplied on tape and reel (TR) for automated assembly. This component is commonly found in automotive and industrial control systems.
Additional Information
Series: EXCELED™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 0603 (1608 Metric) |
| Color | Blue |
| Size / Dimension | 1.60mm L x 0.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 22mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.9V |
| Lens Color | Colorless |
| Current - Test | 5mA |
| Viewing Angle | - |
| Height (Max) | 0.46mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 470nm |
| Supplier Device Package | 1608 (0603) |
| Lens Transparency | Clear |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.20mm x 0.80mm |
Request a Quote
Clients Also Buy
MSL0101RGBU1
